Flex Hose

PROTAPE® PUR 330 AS is a lightweight, microbe-resistant, flame-retardant flex hose built for conveying gases along with abrasive dust, powders, and fibers. Constructed from ester-polyurethane reinforced with a spring steel wire helix, it's highly flexible and compressible at a 3:1 ratio, making it easy to route around equipment and through tight runs. Its permanently antistatic wall (in accordance with ISO 8031) makes it a dependable choice for explosion-hazard areas and static-sensitive operations.

This versatile hose suits extraction systems, dust collection and filtration equipment, oil mist extraction, and extraction arms. It's commonly used on printed circuit board drilling machines, vapor return lines, paint and spray mist extraction, textile fiber extraction, and ventilation systems for barns, clean rooms, and semiconductor production. It also performs well in surface-prep operations such as shot blasting, shipyard work, stripping, floor preparation, and grinding, and can serve as an exterior protective hose in heating applications.

Features

• Ester-polyurethane reinforced with spring steel wire
• Lightweight, highly flexible, and compressible 3:1
• Permanently antistatic wall in accordance with ISO 8031
• Flame retardant, UL94-HB and DIN 4102-B1 rated
• Good resistance to oil, gasoline, and chemicals; microbe- and abrasion-resistant
• Working pressure: 1.958 psi; vacuum rating: 0.591-inch Hg
• Wall: 0.025-inch; bend radius: 6.378-inch
• Temperature range: -40°F to 195°F, and short-term to 255°F
• Meets RoHS guideline; ATEX 2014/34/EU (1999/92/EC) and German TRGS 727
